Teltonika RUT950
Affordable for reliable M2M networking
The Teltonika RUT950 is a compact 4G LTE router with dual SIM for a reliable internet connection. The versatile 4G router is a cost-effective option packed with a lot of security and networking options. Its failover protection isn't limited to 4G backup, but can switch between the two SIM cards as well. Making this Teltonika RUT950 ideal for security cameras, digital signage or telemetry applications.
Teltonika RUT950 Pros and Cons
- Dual SIM for resilient cellular connection
- Automatic switching to 4G backup connection
- Set up a secured WiFi hotspot for guest visitors
- Larger external antennas can be installed, if needed
- Ability to maintain an internet connection with Ping Reboot
- WiFi class N is three times slower than AC
- Use a RUT955 if you require serial and I/O ports
Features
LTE Cat4 Industrial cellular router
The Teltonika RUT950 Dual SIM router combines a rugged, compact router with 4G and 3G technology. This provides speeds up to 100Mbps download and 50Mbps upload. These speeds are perfect for connecting cameras, telemetry or uploading signage content. Create a wireless access point or use the integrated 4-port ethernet switch to connect other devices. This RUT950 has excellent options to create guest networks via WiFi for up to 100 users at a time. But if you want many users with fast internet of cellular there are better options available.
Reliability and data redundancy
Maintaining an internet connection on the 4G router seems like the most basic feature and is often overlooked. With Ping reboot the teltonika RUT950 has the ability to reboot if the connection is ever lost. Preventing a onsite visit for a simple , but now costly task. Dual SIM further helps this router to be reliable. Configure when the router should switch from it's primary SIM to the second SIM. In combination with Olivia multi-network SIMs it's almost impossible to lose your connection. That's why this RUT950 is already a good option for high availability applications without breaking the bank.
The right data plan for any RUT950 use-case
Data plan for 4G/LTE as primary connection
Using cellular as the primary connection usually results in a consistent data usage per month. With our pooled data plans routers can share available data between them.
Flexible plan for backup SIM card
The dual sim feature on the RUT950 is great for data redundancy. But since this connection is hardly used, you want the costs of this connection to be minimal. Olivia’s flexible plan is a low-cost monthly subscription to keep the connection alive. Only when data on this backup sim is used, your charged with a usage fee.
Remotely access the RUT950
Several options are available to manage the router remotely. Included is our remote management solution, which allows to reach the router via our platform without a fixed public IP address. In addition, we have several VPN options to securely connect the router to any server.
Documentation
RUT 950 Firmware Updates
Keep the Teltonika RUT950 up-to-date with firmware updates. Go to the Teltonika firmware libary.
Teltonika RUT950 User manual
Discover all the Teltonika RUT950 can do. Find the user guides in the Teltonika manual libary.
Technical Specifications
Hardware
Mobile 4G (LTE) – Cat 4 DL up to 150 Mbps, UL up to 50 Mbps; DC-HSPA+; UMTS; TD-SCDMA; EDGE; GPRS
CPU Atheros Wasp, MIPS 74Kc, 550 MHz
Memory 16 MBytes Flash, 128 MBytes DDR2 RAM
Ethernet 4 x 10/100 Ethernet ports: 1 x WAN (configurable as LAN), 3 x LAN ports
Power supply 9 – 30 VDC, 4 pin DC connector PoE (passive) Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af and 802.3at standards
Inputs/Outputs 1 x Digital Input, 1 x Digital Open Collector Output on power connector
Connectors 1 x 4 pin DC, 4 x Ethernet, 2 x Mobile SMA, 2 x WiFi RP-SMA
SIM 2 x external SIM holders
Status LEDs 1 x bi-color connection status, 5 x connection strength, 4 x LAN status, 1 x Power
Operating temperature -40 °C to 75 °C
Housing Aluminium housing, plastic panels
Dimensions 100 mm x 110 mm x 50 mm
Weight 256 g
Software
Operating system RutOS (OpenWrt based Linux OS)
SIM switch 2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail
Multiple PDN Possibility to use different PDNs for multiple network access and services
Network protocols TCP, UDP, IPv4, IPv6, ICMP, NTP, DHCP, DNS, HTTP, HTTPS, SSL v3, TLS, ARP, PPPoE, UPNP, SSH, Telnet, SNMP
Networking features NAT, Static/Dynamic routing, Firewall, OpenVPN, IPSec, H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
Unique networking features VLAN, Load balancing, Mobile quota control, WEB Filter, Load Balancing, Network Backup, Auto Failover
Connection monitoring Ping Reboot, Periodic Reboot, Wget Reboot, LCP and ICMP for link inspection
Authentication Pre-shared key, digital certificates, X.509 certificates
Keep settings Update FW without losing current configuration
Monitoring & Management WEB UI, SSH, SMS, SNMP, JSON-RPC, FOTA, RMS
Supported languages Busybox shell, Lua, C, C++
Development tools SDK package with build environment provided
Warranty The RUT950 includes two years warranty as standard. Extended warranty available upon request.
Teltonika RUT950 Alternatives
Frequency Band Support
Different countries use different frequencies and bands. Make sure to use the right version of the Teltonika RUT950 in each country of deployment. Please contact us if you have any hesitations about which version to use.
RUT950 V Global
4G (LTE-FDD): B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28
4G (LTE-TDD): B38, B39, B40, B41
3G: B1, B2, B4, B5, B6, B8, B19
2G: B2, B3, B5, B8
RUT950 J North America (AT&T)
4G (LTE-FDD): B2, B4, B12
3G: B2, B4, B5
RUT950 H Europe, the Middle East, Africa, Korea, Thailand, India
4G (LTE-FDD): B1, B3, B5, B7, B8, B20
4G (LTE-TDD): B38, B40, B41
3G: B1, B5, B8
2G: B3, B8
RUT950 M South America, Australia, New Zealand, Taiwan
4G (LTE-FDD): B1, B2, B3, B4, B5, B7, B8, B28
4G (LTE-TDD): B40
3G: B1, B2, B5, B8
2G: B2, B3, B5, B8
